Product Overview
| Model |
|
|
RTNC3- |
|
|
| |
|
4.7T |
|
|
| Rated capacity |
|
|
4.7 t |
|
|
| Rated output |
2.85 mV/V±0.1% |
| Maximum safe |
|
|
19 t |
|
|
| overload |
| Non-linearity |
0.02% R.O. typ. |
| Hysteresis |
0.02% R.O. typ. |
| Compensated temperature range |
-10 to +40℃ |
| Safe temperature |
-30 to +80℃ |
| range |
| Temperature effect |
0.007% R.O./10℃ |
| on zero |
| Temperature effect |
0.008% R.O./10℃ typ. |
| on span |
| Input resistance |
4450±100 Ω |
| Output resistance |
4010±0.5 Ω |
| Recommended excitation voltage |
5 V |
| Excitation voltage |
5 to 30 V (Max.60) |
| range |
| Insulation resistance |
20 GΩ or more |
| Degrees of protection |
IP68 |
| Cable |
φ6.5 4 conductor shield cable, Cable end: 5 wires |
| Loadcell material |
Stainless steel |
| Deflection at rated |
|
|
0.12 mm |
|
|
| Weight |
|
|
0.7 kg |
|
|
Technical Specifications
| Specification |
Value |
| Brand |
HBK |
| Unit |
pc |
| Minimum Order Quantity |
1 |
For Complete Datasheets And Additional Specifications Please Request A Quotation.
