Product Overview
| Model |
RTNC3-10T |
| |
| Rated capacity |
10 t |
| Rated output |
2.85 mV/V±0.1% |
| Maximum safe |
40 t |
| overload |
| Non-linearity |
0.02% R.O. typ. |
| Hysteresis |
0.02% R.O. typ. |
| Compensated temperature range |
-10 to +40℃ |
| Safe temperature |
-30 to +80℃ |
| range |
| Temperature effect |
0.007% R.O./10℃ |
| on zero |
|
| Temperature effect |
0.008% R.O./10℃ typ. |
| on span |
|
| Input resistance |
4450±100 Ω |
| Output resistance |
|
| Recommended excitation voltage |
5 V |
| Excitation voltage |
5 to 30 V (Max.60) |
| range |
|
| Insulation resistance |
20 GΩ or more |
| Degrees of protection |
IP68 |
| Cable |
φ6.5 4 conductor shield cable, Cable end: 5 wires |
| Loadcell material |
Stainless steel |
| Deflection at rated |
0.17 mm |
| Weight |
1.2 kg |
Technical Specifications
| Specification |
Value |
| Brand |
HBK |
| Unit |
pc |
| Minimum Order Quantity |
1 |
For Complete Datasheets And Additional Specifications Please Request A Quotation.
