| Specifications | |||||||
|
Model |
C10-3VF | ||||||
| Input power source | AC100〜120V±10%，AC200〜230V±10%，50/60Hz | ||||||
| Output | Control system | PWM system | |||||
| Voltage | 0〜190V (for AC 200V input) | ||||||
| 0〜95V (for AC 100V input) | |||||||
| Automatic switching depending on input power source. | |||||||
| Optional unit C10-TR allows output voltage in 0~190V range (Except C10-5VF(EF)) even with AC100V input | |||||||
| Vibration frequency | Half wave: 45~90Hz, Full wave: 90~180Hz | ||||||
| Intermediate wave: 65~120Hz, High frequency: 180~360Hz | |||||||
| Max. current | 3A | ||||||
| Operating | Constant Voltage mode | Frequency, output voltage set manually | |||||
| modes | Constant amplitude mode | − | |||||
| Auto-tuning mode | − | ||||||
| Additional | Speed selector | Selection of up to 4 amplitude settings by means of external signal | |||||
| features | Start/stop control | Start/Stop control by external signal | |||||
| Output signal | Output signal synchronized to parts feeder operation | ||||||
| Soft start | Start-up time 0.2~4.0 secs | ||||||
| On/Off delay | − | ||||||
| Sensor power source | − | ||||||
| Synchronized | Function | − | |||||
| power output | Control system | − | |||||
| OutputVoltage | − | ||||||
| Max. current | − | ||||||
| Noise tolerant Voltage | Above 1000V | ||||||
| Others | Ambient temperature | 0~40℃ | |||||
| Ambient | 10~90% (no condensation) | ||||||
| humidity | |||||||
| Weight | 0.9kg | ||||||
| Case color | U75-70D (Japan Paint Industry Association) | ||||||
| Compatible equipment | ER-30B,38B,45B | ||||||
| EA-25,30,38,45 | |||||||
| LF-30,40 | |||||||
