| Connection diagram |
ISO 4401-05-04-0-05 |
| Max. pressure [bar] |
315 |
| Max. flow [l/min] |
180 |
| Spool symbol |
Symbol W1 |
| Type of connection |
Subplate mounting |
| Nominal flow [l/min] |
75 |
| Size |
10 |
| Type of actuation |
Electrical with integrated electronics |
| Number of ports |
4 |
| Number of switching positions |
3 |
| Supply voltage |
24 V DC |
| Electrical connector |
Connector 7-pole (6 + PE) |
| Electrical connection description |
Connector 7-pole (6 + PE) according to DIN EN 175201-804 |
| Connectivity |
Analog, command value 4...20 mA |
| Hydraulic fluid |
HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR |
| Seals |
FKM |
