SPECIFICATIONS Pressure range : 0-25 bar t/m 0-1,000 bar Over pressure safety : 2 x pressure range Pressure connection : G1/4” according to DIN 3852-E, provided with CDS damping system Electrical connection : M12 x 1 connector, 4-pins Material : stainless steel Power supply : 10-30 VDC Output signal : 4-20 mA, 2-wire Response time (10A90%) : ≤ 5 ms Accuracy : ≤ 0.5% FSD (BFSL) Repeatability : ≤ 0.1% FSD 1-year stability : ≤ 0.2% FSD Max. permissible temperature - medium : -40 / +125 °C - ambient : -30 / +85 °C Compensated temperature range - zero : ≤ 0.3% FSD per 10 °C - span : ≤ 0.2% FSD per 10 °C Shock resistance : 1,000 kg Vibration resistance : 20 g Weather protection degree : IP-67 Weight : approx. 200 gram
