| Item | Performance characteristics |
|---|---|
| CE Marking Directive Compliance | EMC Directive, RoHS Directive |
| Sensing Height | 100 mm 3.937 in |
| Sensing Range | 0.17 to 1 m 0.558 to 3.281 ft (Note：The sensing range is the possible setting distance between the emitter and the receiver. The sensor can detect an object less than 0.17 m 0.558 ft away.) |
| Element Pitch | 10 mm 0.394 in |
| Number of Emitting/Receiving Elements | 11 Nos. each on the emitter and the receiver, respectively |
| Sensing Object | ø13.5 mm ø0.531 in or more opaque object (Note：Although this product can detect slim objects by using the cross-beam scanning system, the size of the slim object which can be stably detected differs with the setting distance. When this sensor is used to detect slim objects, make sure to confirm stable detection using the actual objects.) |
| Supply Voltage | 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
| Current Consumption | Emitter: 80 mA or less Receiver: 100 mA or less |
| Output | PNP open-collector transistor - Maximum source current: 100 mA - Applied voltage: 30 V DC or less (between output and +V) - Residual voltage: 1 V or less (at 100 mA source current), 0.4 V or less (at 16 mA source current) |
| Output: Utilization Category | DC-12 or DC-13 |
