Specifications
Rated capacity 1.961 kN {200 kgf} ~ 49.03 kN {5 tf}
Safe overload 150% R.C.
Ultimate overload 200% R.C.
Rated output 3 mV/V±0.003 mV/V
Non-linearity 0.025% R.O.
Hysteresis 0.025% R.O.
Repeatability 0.025% R.O.
Creep 0.03% R.O./20 min
Creep recovery 0.03% R.O./20 min
Excitation, recommended 12 V or less
Max. excitation 20 V
Zero balance ±0.03 mV/V
Input resistance 380 Ω ~ 460 Ω
Output resistance 345 Ω ~ 355 Ω
Insulation resistance 2,000 MΩ or more (DC50 V) (between bridge and main body)
Temp. range, compensated -10 ℃ ~ 70 ℃
Temp. range, safe -20 ℃ ~ 80 ℃
Temp. effect on zero 0.05% R.O./10 ℃
Temp. effect on output 0.02% LOAD/10 ℃
Cable φ4.7, 4-cores shielded 6m cable directly attached with Y-type crimp terminal lugs at cable end
Class of protection IP67 or equivalent
Paint Epoxy resin Paint (Black)
Material of element Alloy steel
Durability 1,000,000 times with rated load applied
