Technical Specification
Special featuresOutput Voltage 1 … 9 Volt
Operating voltage18 – 30 VDC
Max. ripple≤ 10 %No load current≤ 10 mA
Switching frequency 100 Hz
Operating temperature-25 ° C to 70 ° C
Temperature drift +/- 8 %
Repeat accuracy≤ 1 %
Linearity≤ 3%
Analog outputPulso_has1
Time delay300 ms
Resolution2,67 V / mm
Reverse voltage protection yes
Protection category IP67
EMC-level DIN EN 60947-5-7:2004-06
Housing material Brass, nickel plated
Material active face PCB
Rated operating current at 40° C< 10 mA
Rated operating voltage
Utilisation categoryDC 13
Contact material CuSn
Contact surface materialNiAu
Contact holder PA 6
Nominal operating voltage 24 V DC
TerminationConnector M12 4pin
internal Load<= 500 OhmFIT / MTTF
