Configuration |
Straight |
|
Actuation |
Lever |
|
Drive Size |
3/8 in. |
|
Drive Type |
Square, Hog-Ring |
|
Forward Torque ft-lbs (Nm) |
150 (203) |
|
Max Reverse Torque ft-lbs (Nm) |
150 (203) |
|
Blows Per Minute |
1500 |
|
Free Speed (RPM) |
13000 |
|
Impacting Sound Level dB(A) -- ISO15744 (pressure/power) |
94.6 / 105.6 |
|
Free Speed Sound Level dB(A) -- CAGI/ANSI S12.41 (pressure/power) |
98.4 / 109.4 |
|
Vibration Level m/s2 (K) |
5.9 (1.6) |
|
Weight lbs (kg) |
2.4 (1.09) |
|
Length in (mm) |
6.6 (168) |
|
Air Inlet Size |
1/4" NPT |
|
Min Hose Size (in) |
3-Aug |
|
Air Consumption @ Load cfm (L/min) |
11 (311) |
|
Average Air Consumption cfm (L/min) |
2.5 (71) |
|
PSI |
90 |
|
Bar |
6.2 |
