Specifications
| Power | DC24V |
| Power Consumption | 24W |
| Discharge volume | 7ml/min |
| Discharge Pressure | 5MPa／8MPa |
| Driving Time | Continuous energization |
| Interval Time | More than 10 seconds |
| Wiring Method | Terminal Connection |
| Use Cartridge | LHL-X100、LHL-W100（P-207とP-207Fのみ） |
| Feed Switch | Yes (optional) |
| Grease level switch | Yes |
| Covers | Flame retardant resin (UL94-V0) |
| IP Standard | IP54 |
| CE Approval | Yes |
| Pump air removal | No driving time restrictions |
| Weight | P-102:1.2kg、107:1.6kg、202:1.2kg、207:1.6kg |
