| Technology |
PROFINET RT |
| Number of ports/channels |
2 (switched) |
| Ethernet interface |
100/1000BASE-TX Ethernet with 2 x RJ45 |
| Fieldbus |
PROFINET RT controller |
| Max. process data size |
1 kbyte input/1 kbyte output data |
| Cable length |
up to 100 m twisted pair |
| Hardware diagnostics |
status LEDs |
| Power supply |
via the E-bus |
| Electrical isolation |
500 V (E-bus/Ethernet) |
| Protocol |
RT |
| Configuration |
via EtherCAT master |
| Current consumption E-bus |
typ. 400 mA |
| Special features |
LLDP, SNMP, Conformance Class B, max. 15 RT devices, min. 1 ms RT cycle |
| Weight |
approx. 75 g |
| Operating/storage temperature |
0…+55 °C/-25…+85 °C |
| Relative humidity |
95 %, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. |
IP20/see documentation |
| Approvals/markings |
CE |
