Type | Pin stroke shape/Spring Plungers Type | Main Body Shape | Bolt Type |
---|---|---|---|
Tip shape | [Needle] R Contact | Environment | Waterproof Type |
Body Material | [Stainless Steel] SUS303 | Contact Material | [Stainless Steel] SUS Hardening HRC50 |
Stroke(mm) | 2.8 | Contact Point Type | Contact type NO |
Cylindrical Outer Diameter(mm) | - | Nominal of Thread (M) | M8×0.75 |
Operating Temperature Range(°C) | 0~80 | Operating Point(mm) | 0.3 |
